2024 Tadano GT-1200XL Truck Mounted Telescopic Boom Crane for Sale

2024 Tadano GT1200XL-2

Standard Equipment

- 5 section boom, single cylinder telescoping with pinning system 41 '-167.3' (12.5 m-51.0 m)

- 33.8' or 58.7' (10.3 m or 17.9 m) quick reeving type bi-fold lattice jib (tilt type) with 3.5°, 25° or 45° pinned offsets and self storing pins.

- Auxiliary lifting sheave (single top) stowable

- 55 ton (50 metric ton) - 3 sheaves with swivel hook block and safety latch for 3/4"(19 mm) wire rope

- 7.9 ton (7.2 metric ton) hook ball with swivel

- Variable speed main hoist with grooved drum, cable follower and 892' of 3/4" cable.

- Variable speed auxiliary hoist with grooved drum, cable follower and 482' of 3/4" cable.

- 2-speed winch

- Tadano electronic load moment indicator system (AML-E2)

- Self-removable counterweight (total 55, 1 ODO lbs}

- Independently controlled outriggers

- Three outrigger extension positions (min/mid/max)

- Outrigger extension length detectors

- Front jack (Fifth jack)

- Trailer coupling device

- Hydraulic circuit for dolly (Elevation, swing and swing brake)

- Smart Chart

- Drum rotation indicator (audible, visible and thumper type) main and auxiliary hoist

- Anti-Two block device (overwind cutout)

- Winch over-unwinding prevention

- Telematics (machine data logging and monitoring system) with HELLO-NET via internet

- Hydraulic oil cooler

- Weighted hook storage compartment

- Tadano twin slewing system and 360° positive slewing lock

- LED work lights

- Positive control

- Eco mode system

- Winch drum cameras

- Annemometer

- Air craft warning light

- Boom angle indicator

- 15° tilt cab

- Self centering finger control levers with pilot control

- Control pedals for boom elevating and boom telescoping

- 3 way adjustable cloth seat with armrests and high back

- Hot water cab heater and air conditioner

- Tinted safety glass and sun visor

- Front windshield wiper and washer

- Roof window wiper and washer

- Power window (cab door)

- 12 V power outlet

- USS port (power supply)

For Carrier:

- Cummins X12 (EPA 2021) direct injection diesel engine

- ZF TraXon 12TX 2615 SO automatic mechanical transmission with electro-pneumatically operated dry-type clutch and automatic gear shifting with 12 forward gears and 2 reverse gears.

- ZF TC27L Transfer case (2 stage)

- Hendrickson independent air suspensions

- 8 x 4 Drive

- Inter wheel differential lock on axles 3 and 4

- Aluminum disc wheels

- Front tires 445/65R22.5 Single x4

- Rear tiers 315/80R22.5 Dual x4

- Air Disc brakes

- Anti-lock braking system (ABS)

Engine compression brake

- BOSCH-Servocom, dual circuit hydraulic and mechanical steering system with emergency steering pump Multi Function Display

- Fuel Tank 1 OD gallon

- Adblue Tank 15 gallon

- Hook block tie down (front bumper)

- Towing hooks-Front and rear

- Carrier mounted storage box

- Aluminum fenders

- Air dryer

- Water separator with filter(high filtration)

- Battery Disconnect Switch

- Backup camera

- Beacon lamp

- Resin full cab

- 3 way adjustable air-cushioned seat

- Tilt telescoping steering wheel

- Hourmeter (Operation from the carrier and superstructure)

- Air conditioning

- USS port (power supply)

- Cruise control

- Clearance sonar (Rear side)

- Tire inflation kit
