Boom:
PM 65026 + J1416 Knuckle Boom (new in 2015)
- Folding Hyd 6 ext Knuckle Boom with Detachable 6 ext jib
- 92′ Horizontal Reach
- Main Boom Horizontal Capacity:
- 48,500 lb @ 8’2″
- 28,260 lb @ 14′ 5″
- 15,340 lb @ 25′ 3″
- 10,000 lb @ 37′,
- 7,210 lb@ 50′ 2″
- Jib Horizontal Capacity:
- 3,850 lb @ 59′ 1″
- 3,000 lb @ 74′ 6″
- 2,340 lb @ 81′ 1″
- 2,100 lb @ 86′ 8″
- 1,800 lb @ 92′
- Maximum Lifting Moment 59 mt (429,640 ft-lbs)
- PM Power-Link connections at Main, Knuckle & Jib Cylinders
- Dual Planetary Gear Motors & Continuous Boom Rotation Double pilot operated on slewing and pilot operated check valves on all cylinders
- 180 degree flip up Hydraulic Extra Wide Main outriggers at pedestal – 28′ – 7″ span
- 360 degree full load chart stability Hydraulic Oil Cooler
- High pressure return filter and min. 100-gallon hyd aluminum oil tank with gate valves mounted at front under deck DANFOSS Proportional Control Valve at Top Seat with Ladder Access- & SCANRECO Proportional Radio Remote Control
- PM- Power Tronic load & function monitoring system, Digital Load Indicator at top seat & remote, electric/hyd overload protection
- Radio Remote Control includes: 2-batteries, in-cab charger, and back-up cord – 5 level turtle (micro) slow down mode
