STANDARD FEATURES
Maximum lifting moment 5.9 mt (42,690 ft-lbs)
Boom length 17' 9" via 1-hydraulic extension
Paltronic 50 Overload Protection System
PowerLink at outer boom
Rotation angle 400 degrees
Outriggers manually extendable to 14' 3" (R2)
STZS3 stabilizers with LED marker lights and 10° tilting stabilizer plates
Dual operator control stations with LED lighting
Bubble level at both outrigger control stations
Load holding valves on slewing, main, outer and extension boom cylinders
Maintenance-free extension boom-system
Return oil utilization
Oil tank 13 US gal.(50 l) with return filter installed at crane base
High pressure filter installed
5.4 metric ton (11,900 lbs) capacity load hook standard
Hour counter with service intervals
Ref no: PO1380C
