STANDARD FEATURES
Max. lifting moment 39.3 mt (284,330 ft-lbs)
Boom length 25' 3" via 2-hyd. ext (A)
Power Link Plus 15°
Continuous rotation via 2 motors (2GETR)
Danfoss 4-section control valve on column, prepared for LS pump
Radio remote control with display on handset, prepared for 6-functions
PAL50 overload protection system with emergency cutoff
High ext. speed with return oil utilization
Provision for lifting capacity limitation dependent on rotation angle (SHB01)
Load holding valves on rotation gears, inner, outer and extension boom cylinders
Fixed hyd. stabilizers (STZS3) with LED marker lights and 10° tilting plates
Hyd. outrigger beams 24' 3" (R3X)
Electrical switch between crane & outrigger controls
Control for outriggers & stabilizers and auxiliary outriggers & stabilizers by two
separate 4-function control valve
Box level at both outrigger control stations
Hour meter w/ service interval ind. High pressure filter
14HP (10.5 kW) cooler installed
Loose 79 US gal. (300 l) oil tank w/ return filter
15 metric ton (33,069 lbs) roller bearing load hook
