Year: 2005
Condition: Very-good
Unit #: UT-432
Location: Houston, Texas
STANDARD FEATURES
BASIC MACHINE:
220,637 ft-lbs max lifting moment
Rear Mounted crane
Qty. (2) hydraulic boom extensions to 26’’7’’ max reach
Lifts 10,080 lbs. @ 20’; 4,980 lbs at 40 feet
400 degree rotation
Telescopic outriggers with hydraulic extension to 19’ 8”
Auxiliary outriggers
Dual 4 section control valve for crane and auxillary stabilizers
Load holding valves on lift, fold, ext. and outrigger cylinders
Hetronic Nova radio remote control
Frame mounted hydraulic reservoir
Air shift PTO w/direct mount piston pump
TRUCK / BED
2005 Sterling LT9500 Chassis
20K front axle w/ 425/65R 22.5 tiresBASIC
40K rear axle w/ 11R 22.5 tires
Caterpillar C-13 Engine, 430 HP
Jacobs engine brake
Eaton Fuller 8LL transmission, 10 speed
Dual 60 gallon fuel tanks
Freightliner Tuff Trac Spring Suspension
Alcoa aluminum wheels
Steel diamond plate flatbed 21’ x 102”” with 4” rub rails & stake pockets
42” headboard w/expanded metal upper portion; 18” expanded metal footboard
Seven (7) D-Rings each side; Fourteen (14) total
(5) sliding winches
(1) Under body tool box –size 36” X 18” X 18” mounted on drivers side
Tool basket mounted under truck bed on passenger side
(2) Strobe lights mounted on rear of truck
Pintle hitch w/ D-Rings and A & E
(2) work lights mounted on rear of body
Current miles: 267,000
