STANDARD FEATURES

Maximum lifting moment 20.9 mt (151,190 ft-lbs)

Paltronic 50 Overload Protection System

Boom length 26' 11" via 2-hydraulic extensions (A)

Outer boom tilts 15° above horizontal (Power Link Plus)

Rotation angle 400°

Outriggers hydraulically ext. 18' 6" (R2X), fixed hyd. stabilizers (STZS)

4-function Danfoss control valve

BMS-2 radio remote control with Paltronic 50 display on handset, prepared for 6- functions

Single ground control station

No spare control valve sections

Bubble level at both outrigger control stations

Load holding valves on slewing, inner, outer and extension cylinder

Maintenance-free extension system with return oil utilization

Oil tank 53 US gal.(200 l) with return filter, loose

11.4 HP oil cooler and high pressure filter installed

8 metric ton (17,640 lbs) capacity roller bearing load hook

Hour counter with service intervals (12 V power required)
