STANDARD FEATURES

Maximum lifting moment 14.6 mt (105,580 ft-lbs).

Paltronic 50 Overload Protection System.

Boom length 20' 4" via 1-hydraulic extension.

Rotation angle 420 degrees.

Outriggers manually extendable to 15' 1" (R1).

Includes 2 additional valve sections.

Dual operator control stations (not possible in combination with radio remote).

Bubble level at both outrigger control stations.

Load holding valves on main, outer and extension cylinders.

Extension system with return oil utilization.

Oil tank 21 US gal.(80 l) with return filter installed at crane base.

High pressure filter installed. 8 metric ton (17,640 lbs) capacity roller bearing load hook.

Hour counter with service intervals (12 V power required)

Mounting hardware kit (UZ 265)

INCLUDED OPTIONS

KZS01 Cylinder Guard

4-section hydraulic boom extension”

R2X outriggers – hydraulically extendable to 18’4”

F1-61-R Parker voac piston pump

2” 45 degrees suction fitting
