Technical Specifications:

Static moment at the turret pin: 34500 (daN/m), 254460 (lbs/ft)

Hyd. boom length: 16230 (mm), 53’3” (in)

Length: 1220 (mm), 4' 0'' (in)

Width: 2550 (mm), 8' 4'' (in)

Height: 2250 (mm), 7’ 5'' (in)

Weight (without oil and fitting): 4070 (kg), 14771 (lbs)

Lifting capacity: 6700 (kg), 14771 (lbs)

Slew torque: 3700 (daN/m), 27290 (lbs/ft)

Slewing speed: 360° - 33 (° – sec), 360° - 33 (° – sec)

Outriggers extension: 1500+1750 (mm), 4' 11''+5' 9'' (in)

Outriggers width: 5630 (mm), 18'6'' (in)

Pump delivery: 60 (lit/min), 16

Pressure: 280 (bar), 4061 (Psi)

Oil tank capacity: 160 (lit), 42 (us gal)
