STANDARD FEATURES

16,314 lifting capacity (254,460 ft lbs)

Max static moment at the turret pin: 254,460 ft lbs

Hydraulic boom length: 34’ 4” (optional 87’ 1” hydraulic boom length)

Slew torque: 27,290 ft lbs

Pressure: 4,061PSI

Radio Remote

Negative angle between 1st and 2nd boom (20 degrees)

Cylinders locking system when crane is folded

Controls can be reached standing on the side

All the carters are in stainless steel

Danfoss proportional control bank

Heat exchanger

All cylinders with single extension

Height speed extension standard

Negative angle between extensions and jib (20 degrees)

8th hydraulic extension with intern cylinder

OPTIONS

2500 daN Winch on the 1st line

Full power circuit, greatest power

180 degrees tilting stabilizing cylinder

FLY-Jib available
