New Cormach 28200E6 knuckle boom crane (unmounted)
Technical specifications:
Static moment at the turret pin: 28200 (daN/m), 207992 (lbs/ft)
Hyd. boom length: 15500 (mm), 50' 10" (in)
Length: 1007 (mm), 3' 4" (in)
Width: 2500 (mm), 8' 2" (in)
Height: 2230 (mm), 7' 4" (in)
Weight (without oil and fitting): 3340 (kg), 7363 (lbs)
Lifting capacity: 9700 (kg), 21385 (lbs)
Boom length with manual extensions: 20000 (mm), 65' 7" (in)
Slew torque: 2800 (daN/m), 20652(lbs/ft)
Slewing speed: 360° - 40 (° – sec), 360° 40 (° – sec)
Outriggers extension: 1750 + 1750 (mm), 5' 9" + 5' 9" (in)
Outriggers width: 5838 (mm), 19' 2" (in)
Pump delivery: 45 (lit/min), 12
Pressure: 310 (bar), 4496 (Psi)
Oil tank capacity: 155 (lit), 41 (us gal)
