Donaldson dry-type air cleaner w/safety element & restriction indicator (with TaylorMax Precleaner)
Dana TE-30 5-speed powershift transmission
Powertrain protection system for engine and transmission
Kessler D-102W HD planetary drive axle with wet disc brakes
Taylor 800 welded steel steer axle with stud protectors (single hydraulic cylinder design with heavy-duty links from the cylinder ram directly to tapered roller bearing mounted spindles)
CHASSIS
All-welded steel frame with 4 lifting eyes (lifting eyes not designed for level pick)
Bolted counterweight
Replaceable bolt-on steps and handrails
Lockable Fuel Cap
Removable deck plates open to expose drive train for ease of maintenance
CAB
Climate Controlled sliding (hydraulic/electric) all-welded steel center mount cab (includes right hand and left hand access doors with rear exit window and dome light)
66,000 BTU total heating with front and rear defrosting, cab pressurizer and fresh air intake
40,000 BTU air conditioning and two circulation fans
Exterior Cab Positioning Switch allows the cab to be moved while the machine is powered down
Tinted glass with front, rear, and top windshield wipers
Front and Top windshield washer
Fully adjustable air ride swivel seat with 35° of rotation (15°/20° left-right)
Multifunction joystick, with integrated directional shift control, mounted on adjustable arm rest
Operator Restraint System (Orange, anti-cinch seat belt with starting sequence neutral lock)
Operator Presence System with timed idle and neutral shutdown (5 minute default, password adjustable from 1-120 minutes by end user)
Taylor Integrated Control System (TICS) …see next page for additional info
TaylorTrak Pro - Advanced Fleet Telematics hardware
7-in touch screen color display
Rear visibility aid camera system
The 2-piece flip-down instrument panel is pre-wired to accommodate heavy-duty accessories.
All wiring is color and number coded.
Dual USB charging ports
Hydrostatic, steer-on-demand power steering with tilt steering column
ELECTRICAL
24-volt electrical system with 110 amp alternator
Dual heavy-duty batteries
Dual Battery disconnect/lock-out switch
2 Sets of Amber/Green/Red Twistlock operation signal lights (mounted in cab and on boom)
(4) Chassis mounted LED work lights
(4) Boom mounted LED work lights
(2) Dedicated Twistlock LED work lights
(2) LED step lights
Stop-Tail-Turn Lights
Circuit breakers with heavy duty connectors (no automotive type fuses)
