New 2017 Manitou TMT 55 HT 4W all-terrain truck mounted forklift

New 2017 Manitou TMT 55 HT 4W all-terrain truck mounted forklift Telescopic MANITOU TMT55HT4W CraneWorks Inc. 23867 on CraneNetwork.com
Last Updated: 30 Aug, 17
  • Year: 2017
  • Hours: Inquire
  • Location: Kansas, United States
  • Condition: New
  • Serial #: 880332
  • Unit #: FL-264
Request a Quote
Email Seller
Save to Favorites
Make an Offer

The TMT 55 HT 4W is an all-terrain truck-mounted forklift designed for loading and unloading lorries and making customer deliveries even when ground conditions aren't as smooth as they could be, or when customers don't have a loading/unloading bay. It's incredibly useful in the construction sector for materials delivery with its increased robustness and reduced payload.

Built to last, the controls are incredibly easy to to grasp and upkeep has been simplifed as well. With offset and lateral movement modes, it can load and unload lorries from a single side with no problems. This is particularly useful when lorries are parked alongside a wall, on the side of the road or if you have to navigate a narrow path.

Standard equipment

Rain Cap

Outside right rear-view mirror

Certified driver guard

Three-function FNR handling levers

Boom with integrated side shift

Battery Master Switch

Stabiliser on front wheel arms

Imitation leather seat

Internal rear-view mirror

Anti-slip step

Right-hand side grill

3 drive wheels with hydrostatic transmission

Wide handle

Belt-linked engine cut-off

4 Way System

Flashing Light


Lifting height: 3.43 m, 11'3"

Lifting capacity: 2500 kg, 5500 lb

Max reach: 1.47 m, 4'1"

Max reach capacity: 793 kg, 1750 lb

Drawbar pull: 2100 dan, 4800 lbf

Moving speed: 11 kmh, 7 mph


Length (up to the back of the fork): 2.92 m, 9'7"

Width: 2.57 m, 8'5"

Height: 2.45 m, 8'0"

Weight (unladen): 2722 kg, 6000 lb

Turning radius: 2.61 m, 8'7"

Ground clearance: 0.25 m, 0'10"


Energy: Diesel

Engine brand: Kubota

Engine type: Tier IV Final

Engine manufacturer type: D1803-CR

Power: 50 ch, 49 hp

Power: 37 KW

Number of cylinders: 4

Total capacity: 2434 cm3, 148.5 in3

Injection: Direct

Cooling: Water

Transmission type: Hydrostatic


Flow: 46 l/min

Pressure: 245 bars

Hydraulic oil tank volume: 45 l, 12 gal

Other specifications

Standard tyres: Pneumatic

Number of wheels (front/rear): 2/1

Number of drive wheels (front/rear): 2/1

Tyre dimensions (front): 31 x 10 - 16,5"

Tyre dimensions (rear): 31 x 10 - 16,5"
