2025 National NBT45-2 Boom Truck Crane
Dan Runnion: 708-541-1066
Last Updated: 08 Nov 2024
Capacity: 45.00
Condition: New
Unit #: 5052N
National Crane NBT45-2 equipped as follows:
- 45-ton capacity
- 5-section boom 31’ – 127’, 192’ tip height
- Three quick reeve cast iron sheaves
- 31’ - 55’ manually telescoping jib
- Two (2) total rotating, superstructure mounted, non-removable counterweight slabs, 6,000 lbs
- Rated Capacity Limiter (RCL) and anti-two block system; graphical, color RCL system with audio/visual warning system and control lever lockout. Electronic display of boom angle, boom length, relative load moment indication, rated load, load, radius and boom tip height.
- Internal anti-two block system.
- Standard work area definition system (WADS) allows the operator to pre-select and define safe working areas. When crane approaches set limits, audio/visual warnings alert the operator of jobsite obstructions
- 0° to 20° tilting cab with all steel construction crane cab, acoustical lining, and tinted glass
- Deluxe heated seat with armrest mounted dual-axis electric controllers
- Windshield with electric wiper
- Sliding skylight with sunshade
- Hot water cab heater with defroster (diesel fired with remote diesel tank mounted to cab)
- Air conditioning and circulating fan
- AM/FM/Bluetooth radio with two (2) speakers
- Fire extinguisher
- Dual cab mounted work lights
- Engine start/stop switches
- Signal horn
- 360-degree continuous rotation
- Planetary glide swing with foot actuated multi-disk brake and pinion guard
- Pressure compensated, load sense, closed center hydraulic system
- Variable displacement piston pump
- 122-gallon hydraulic reservoir
- Filter condition indicator
- Oil temperature transducer and oil cooler with electric fan and butterfly valve on suction line
- Main hoist with grooved drum, two-speed power up and down, automatic multi-disc brake, electronic drum rotation indicator and drum cable follower. Bare drum maximum pull 17,250 lbs.
- 450’ of 5/8” diameter 35x7 wire rope (5:1 design factor) for main hoist
- Single line pull 11,280 lbs.
- 20-ton single sheave “Quick Reeve” type block with swivel hook and safety latch
- Hydraulic front and rear outriggers. Two section extendable beams with integral check valves. 20” diameter polymeric outrigger floats. Controls located in crane cab and on both sides of sub frame.
- Single front outrigger
- Hydraulic reservoir mounted on top of front outrigger box
- Outrigger Monitoring System included
- Outriggers have three position settings (0%, 50%, 100%)
- Outrigger motion alarm
- 360 degrees stable
- Back-up alarm
- Marker and indicator lights
- Full-length aluminum decking – 102” wide
- Fold down ladder on driver’s side for crane cab access
- One removable ladder stowed/locked at the rear of the crane frame
MOUNTED ON:
2025 Freightliner 114SD equipped as follows:
- Cummins X12 engine, 500 hp at 1900 rpm, 1700 ft/lbs at 1000 rpm
- Allison 4500 RDS automatic transmission
- 20,000lb front axle with flat leaf suspension
- 46,000lb tandem rear axle with Airliner suspension
- 13,500lb steerable pusher axle with Air lift suspension
- Differential lock tandem axles
- Air dryer with heater
- Tires: Front – Michelin XZE 425/65R22.5 front tires
- Tires: Rear – Continental HDR2+ 11R22.5 rear tires
- Tires: Tag – Continental HS3+ ECO PLUS 295/75R22.5
- Aluminum wheels
- 90-gallon fuel tank with painted steel bands
- 13-gallon DEF tank
- Drivers Seats – Air ride, high back, black Cordura
- Passenger Seat – Non-suspension, mid back, toolbox, black Cordura
- Adjustable steering column - tilt/telescope
- Cruise control
- Power door locks and windows
- Air conditioner
- Backup alarm
- Triangle reflectors
- 5 lbs fire extinguisher
- AM/FM/WB radio with Bluetooth, USB, and Aux inputs
- Heated mirrors
- Painted white
Runnion Equipment Co.
www.runnionequipment.comContact: Dan Runnion, Sales
Phone: 708-541-1066
Fax: 708-447-3730
