Base Machine Includes:

• 50 ft of basic boom (butt and top sections)

• Isuzu 6UZ1 Diesel Engine (Tier Four rated) rated at 362 hp at 2000 rpm

• Engine “G-Mode” to allow for upwards of 30% fuel savings

• Kobelco LMI w/12” display and A2B system with overload protection and alarms as well as third wrap sensors

• Main and Auxiliary Winches with Freefall option included and machine prepped for 3rd drum

• Main Winch holds 902’ of 26mm wire rope with 29,500 lbf of rated line pull

• Auxiliary Winch holds 837’ of 26mm wire rope with 29,500 lbf of rated line pull

• 154,100 pounds of Counterweight and Carbody Weights

• Self Lifting Device for counterweight installation.

• 106 US gallon (400 litre) fuel tank

• 121.5 gallon (460 litre) Hydraulic Reservoir w/cooler and full flow filters with replaceable elements

• 24 volt electrical system

• Quick Disconnect Track/Crawler Frames

• 48” track pads with approximately 11.8 psi ground bearing pressure and 30% gradeability

• Operators Cab is fully enclosed, full vision w/safety glass, air conditioner/heater, signal horn, windshield wipers, and swing limiter

• Kobelco KCross Telematics

• Upper machinery catwalk, ladders and handrails

• Two (2) front flood lights

Main Boom Includes the following for a total of 200’ of boom :

• One (1) 10’ Boom Insert

• One (1) 20’ Boom Insert

• One (1) 40’ “A” Boom Insert (w/ lug)

• One (2) 40’ Boom Insert (w/o lug)

Lifting Accessories Included:

• One (1) 75 ton capacity, three (3) sheave Hook Block

• One (1) 19 ton capacity Overhaul Ball Hook

• Boom Tip Auxiliary Sheave (Rooster Sheave)
