150 Feet of Tube Boom with Hydraulic Quick Draw for Machine Assembly / Disassembly

v  22-foot Live Mast with Rigid Sheave Guard, 12-Part Boom hoist Reeving

v  Hydrostatically Driven Side Frame Assemblies Provide 14’-2” Extended Gauge

v  Side Frames are Equipped with 36” Track Shoes and Mechanical Track Adjustment

v  Three (3) Variable Displacement Piston Pumps Provide Control for Hoist Drums, Travel, and Swing

v  Three (3) Gear Type Pumps are Used for Pilot Pressure, Cylinder Retract, and Counterweight Removal

v  Matching Front and Rear Hoist Drums include Power Up/Down or Freefall

v  Auxiliary 5 Foot Tip Extension Provides Clearance Between Working Lines

v  Full Upper Counterweight Package (A+(2) B wing weights +C) with Hydraulic Removal and Install

v  Two (2) Lower Carbody Counterweights

v  Cummins QSB 6.7, Stage 5 Diesel engine, Providing 282 HP.

v  Fully Enclosed Operator’s Cab with AM/FM Radio, Heater, and Air-Conditioning

v  Next Generation Load Moment Limiter with Color Graphic Display

v  Single-Axis Armchair Mounted Control Levers

v  Left and Right-side Upper Handrails, and Left and Right-side Upper Catwalks

v  90 Ton Hook Block

v  15 Ton Headache Ball
