Features

Jobsite accessibility: Most compact crane in its capacity class with a total length of 14.0 m and a carrier width of 2.75 m

IC-1 Plus: Real time calculation of lifting capacities allows working in a higher capacity range with less counterweight; this increases versatility and reduces transport costs

Reduced operational costs: Single engine concept, start-stop function and an intelligent motor management system reduces operational cost and maintenance

Clean axle loads: The crane stays under the 12 t axle load limit, still being able to carry up to 650 kg of payload

Excellent maneuverability: All-axle steering, independent rear axle steering and dynamic launch control

Specifications

Capacity class: 160 t, 180 US-tons

Main boom length: 68 m, 223.1 ft

Maximum system length: 95 m, 311.7 ft

Maximum counterweight: 46,0 t, 50.6 US-tons

Overall length: 14,51 m, 47,6 ft

Carrier length: 12,61 m, 41,4 ft

Turning radius over cabin / all axle steered: 12,68 / 11,28 m, 41.6 / 37.0 ft

Carrier engine: 368 kW, 500 hp

Maximum travel speed: 85 km/h, 53 mph

Drive chain (optional): 10 x 6 x 10 (10 x 8 x 10)

Tires: 14.00 (16.00 / 20.5)

Maximum gradeability: 64%
