Features

40 US-tons (36 t) Maximum Capacity

105 ft (32 m) Maximum Boom Length

110 ft (33.5 m) Maximum Tip Height

Engine Power 300 hp (224 kW)

Travel Speeds up to 60 mph (96 km/h)

Specifications

Capacity class: 36 t, 40 US-tons

Main boom length: 32.0 m, 105 ft

Maximum tip height (with extension): 48.2 m, 159 ft

Maximum boom length: 46.9 m, 154 ft

Maximum counterweight: 4,990 kg, 11,000 lb

Overall length: 11.8 m, 38 ft 9 in

Carrier length: 10.1 m, 33 ft 1 in

Turning radius over cabin / all axle steered: 10.4 m, 34 ft

Carrier engine (2010 EPA): 224 kW, 300 hp

Maximum travel speed: 96 kph, 60 mph

Drive train: 6 x 4

Tires - front: 445/65 R22.5-20PR

Tires - rear: 11R22-14PR

Maximum gradeability: (manual transmission) 56%

Maximum gradeability (automatic transmission): 64%
