2024 Tadano GT-1200XL-2 Quote: 5 section boom, single cylinder telescoping with pinning system 41’-167.3’ (12.5m-51.0m) 33.8’ or 58.7’ (10.3m or 17.9m) quick reeving type bi-fold lattice jib (tilt type) with 3.5’ or 45’ pinned offsets and self storing pins Auxiliary lifting sheave (single top) stowable 55 ton (50 metric ton)- 3 sheaves with swivel hook block and safety latch for ¾†(19 mm) wire rope 7.9 ton (7.2 metric ton) hook ball with swivel Variable speed main hoist with grooved drum, cable follower and 892’ of ¾†cable Variable speed auxiliary hoist with grooved drum, cable follower and 482’ of ¾†cable 2-speed winch Tadano electronic load moment indicator system (AML-E2) self -removable counterweight (total 55,1000 lbs) Independently controlled outriggers Three outrigger extension positions Outrigger extension length detectors Front jack (fifth jack) Trailer coupling device Hydraulic circuit for dolly (elevation, swing and swing brake) Smart chart Drum rotation indicator (audible, visible and thumper type) main and auxiliary hoist Anti-two block device Winch over-unwinding prevention Telematics (machine data logging and monitoring system) with HELLO-NET via internet Hydraulic oil cooler Weighted hook storage compartment Tadano twin slewing system and 360 degree positive slewing lock Positive control LED work lights Eco mode system Winch drum cameras Boom angle indicator Air craft warning light 15 degree tilt cab Self centering finger control levers with pilot control Control pedals for boom elevating and boom telescoping 3 way adjustable cloth seat with armrests and high back Hot water cab heater and air conditioner Tinted safety glass and sun visor Front windshield wiper and washer Roof window wiper and washer Power window (cab door) 12 V power outlet USB port (power supply) Anemometer Carrier Specs Cummins X12 (EPA 2021) direct injection diesel engine, turbo charged and after cooled w/500 HP (373 kW) and Max. Torque of 1,700 ft-lb (2,305 Nm) ZF TraXon 12TX 2615 SO automatic mechanical transmission with electro-pneumatically operated dry-type clutch and automatic gear shifting with 12 forward gears and 2 reverse gears ZF TC27L transfer case (2 stage) Hendrickson independent air suspensions 8X4 drive Inter wheel differential lock on axles 3 and 4 Aluminum disc wheels Front tires: 445/65R22.5 single x 4 Rear tires: 315/80R22.5 dual x 4 Air disc brakes Anti-lock braking system (ABS) Engine compression brake BOSCH-servocom, dual circuit hydraulic and mechanical steering system with emergency steering pump Multi Function display Fuel tank 100 gallons Adblue 15 gallon tank Hook block tie down (front bumper) Towing hooks front and rear Carrier mounted storage box Aluminum fenders Air dryer Water separator with filter Battery disconnect switch Backup camera Beacon lamp Resin full cab 3 way adjustable air cushioned seat Tilt telescoping steering wheel Hourmeter Air conditioning USB port (power supply) Cruise control Clearance sonar (rear side) Tire inflation kit
