Technical Specifications: HOOK HEIGHT: Maximum hook height is 98 ft. (30 m) with jib set at 0Ëš and 141 ft. (40 m) with jib set at 20Ëš. JIB: Jib length is 131 ft. (40 m). HOIST: The 18 HPL 10 "High Performance Lifting" variable frequency hoist offers line speeds up to 213 ft/min (65 m/min). WIRE ROPE: Ample wire rope to reach the ground with a permanent four-part line. HOOKBLOCK: Permanent 4 Fall Hookblock. TROLLEY: The 3 DVF 5 trolley is capable of speeds up to 148 ft/min (45 m/min). SWING: The HPS 142 "High Performance Slewing" motors allow the crane a maximum swing speed of 0.9 RPM. LUBRICATION: Automatic greasing of the slewing ring. REMOTE CONTROL: Radio remote control with "Smart Set-Up" and auxiliary tethered remote are standard. OUTRIGGERS: 14.76 ft x 14.76 ft (4.5 m 4.5 m) center to center of outrigger pads. ELECTRICAL REQUIREMENT: 480 volt, 60Hz, measured at the turntable.
