55 US ton capacity

Four section full power synchronized boom 35.1’-113.9’ (10.7 m-34.7 m)

50’ (15.2 m) bi-fold lattice jib (tilt type)

Auxiliary lifting sheave (single top) storable

Variable speed main hoist with grooved drum, cable follower and 633’ of ¾” cable

Variable speed aux. hoist with grooved drum, cable follower and 361’ of ¾” cable

Drum rotation indicator (audible, visible and thumper type) main and aux. hoist

Anti-two block device (overwind cutout)

Boom angle indicator

Tadano electronic load moment indicator system (AML-C)

Outrigger extension length detector

Electronic crane monitoring system

Tadano twin slewing system and 360 degree positive slewing lock

Self centering finger control levers with pilot control

Control pedals for boom elevating and boom telescoping

3 way adjustable cloth seat with armrests, high back and seat belt

Tilt-telescoping steering wheel

Tinted safety glass and sun visor

Front windshield wiper and washer

Roof window wiper and washer

Power window (cab door)

Rear view mirrors (right and left side)

Mirror for main and aux. hoists

Cigarette lighter and ashtray

Cab floor mat

Pump disconnect in operator’s cab

Hydraulic oil cooler

Hot water cab heater and air conditioner

Positive control

Quick reeving type bi-fold jib

Work lights

Independently controlled outriggers

Four outrigger extension positions

Self-storing outrigger pads

Cummins QSB6.7 turbo charged after cooled engine (270HP) with exhaust brake

Electronic controlled automatic transmission driven by torque converter

4 x 4 x 4 drive/steer

Non-spin rear differential

Semi-elliptic leaf springs suspension with hydraulic lockout device (front and rear)

Disc brakes

Fenders

Air dryer

Water separator with filter (high filtration)

Engine over-run alarm

Back-up alarm

Low oil pressure/high water temp. warning device (visual)

Rear steer centering light

Air cleaner dust indicator

Full instrumentation package

Complete highway light package

Tool storage compartment

Tire inflation kit

24V electric system

6.2 ton (5.6 metric ton) hook ball with swivel

55 ton (50 metric ton) 5-sheave with swivel hook block and safety latch for ¾” (19 mm) wire rope

Towing hooks-Front and rear

Lifting eyes

Hook block tie down (front bumper)

Weighted hook storage compartment

Halogen head lamp

Telematics (machine data logging and monitoring system) with HELLO-NET via internet

Fuel consumption monitor

Eco mode system

Hours 4411 Sept 29 2020
