Tadano Rough Terrain Crane, Model GR1600XL-3, C/W: 160 Ton Capacity (145 Metric Tons) Six section boom, single cylinder telescoping with hydraulic system 41.8’ - 200.1’ (13.1m - 61.0m) 33.8’ or 59.1’ (10.3m or 18.0m) bi-fold lattice jib (tilt type) with 0, 20 or 40 degree hydraulic offsets and self stowing pins Quick reeving type bi-fold jib Auxiliary lifting sheave (single top) storable Variable speed main hoist with grooved drum, cable follower and 1,050’ of ¾†cable Variable speed auxiliary hoist with grooved drum, cable follower and 738’ of ¾†cable Drum rotation indicator (audible, visible and thumper type) main and auxiliary hoist Anti-block device (overwind cutout) and lower limit (3rd wrap) Boom angle indicator Tadano electronic load moment indicator system (AML-C) Outrigger extension length detector Tadano twin slewing system and 360 degree positive slewling lock Tilting cab Self centering finger control levers with pilot control Control pedals for boom elevating and boom telescoping 3-way adjustable cloth seat with armrests, high back and seat belt Tilt-telescoping steering wheel Tinted safety glass and sun visor Front windshield wiper and washer Roof window wiper and washer Power window(cab door) Rear view mirrors (right and left side) Mirror for main and auxiliary hoists Cigarette lighter and ashtray Cab floor mat Pump disconnect in operators cab Hydraulic oil cooler Air conditioner (not water heater and cooler) Positive control Work lights Independently controlled outriggers Four outrigger extension positions Cummins QSB6.7 (Tier 4) turbo charged after cooled engine (270HP) with exhaust brake Electronic controlled automatic transmission driven by torque converter 6 x 4 x 8 x drive/steer Automatic 2nd and 3rd axle oscillation lock out system 26.5 R25 tires Disc brakes Fenders Air dryer Water separator with filter (high filtration) Engine over-run alarm Back-up alarm Low oil pressure/high water temp warning device (visual) 2nd and 3rd steer centering light Air cleaner dust indicator Tool storage compartment Tire inflation kit 24 volt electronic system 7.9 ton (7.2 metric ton) hook ball with swivel 110 ton (100 metric ton) 7-sheaves with swivel hook block and safety latch for ¾†wire rope Weighted hook storage compartment Hook block tie down (front bumper) Towing hooks - front and rear Lifting eyes Halogen head lamp Telematics (machine data logging and monitoring system) with HELLO-NET via internet Fuel consumption monitor Eco-mode system Self-removable counterweight (40,100 + 24, 500 = 64,000 lbs) Self-removable outrigger boxes Emergency steering assist Anemometer Aircraft warning light
