Features
EC2000 electric service crane 2,000 lb. capacity with 7′ horizontal reach Stellar® EC2000 Electric Service Cranes combine the lifting power you need with the economy you want. You’ll handle a wide range of lifting needs, and you won’t have to spend valuable time and money refueling. Because the EC2000 doesn’t require a PTO and pump, operation is significantly quieter than hydraulic cranes so you can work at times and in locations where reduced noise is essential. EC2000 includes: - Ball Bearing Rotation Gear for solid support and smooth operation - Steel Worm Gear for reliable speed control when rotating the shaft, available on powered rotation models - Planetary Winch that lifts the maximum crane load and offers the smoothest and fastest speeds in the market today for maximum productivity - Low-Profile Design for superior clearance - Integral Rotation Stop with 340° manual rotation or 310° powered - Certification for ANSI B30.5 and OSHA 1910.180 specifications - Tall or Short Masts - Powered Rotation or Manual Rotation Specifications - Crane Rating: 6,500 ft-lbs (0.99 tm) - Standard Boom Length: 4' (1.22 m) from CL of crane - Boom Extension: - 1st Stage: Manual 18" (45.72 cm) - 2st Stage: Manual 18" (45.72 cm) - Maximum Horizontal Reach: 7' (2.13 m) from CL of crane - Maximum Vertical Lift: 10' 9" (3.28 m) from crane base - Lifting Capacity: - 1,580 lbs @ 4' (715 kg @ 1.219 m) - 930 lbs @ 7' (422 kg @ 2.13 m) - Boom Elevation: 0° to +21° to +56° - Stowed Height (crane only): - 60" (152.4 cm) - Short mast version 30" (76.2 cm) - Mounting Space Required: 12" x 12" (30.5 x 30.5 cm) - Approximate Crane Weight: 275 - 300 lbs (124.7 - 136.1 kg) - Controls: Tethered remote - Winch: - Rope Diameter: 3/16" (0.48 cm) - Rope Length: 40' (12.19 m) - Line Pull Speed: 20 ft/min (6 m/min) - Rotation: 340° manual (optional 314° power rotation available) - Min. Rec. Chassis (GVRW)*: 8,600
