Included along with the basic machine are the following optional equipment items:
Self Erect Options: Includes two wire rope guides for crawler handling, boom butt handling cyclinder, upperworls jacking cylinders with pads, alignment device, four carbody support pedestals, 45-ton assembley block (see below), crawler handling chains and 160' of 1-1/8 diameter rigging line.
Series 2 and 3 Counterweight Option: Includes 80,000lb upperworks counterweight and 120,000lb carbody weight.
Operators Cab: Air conditioner for operators cab.
Lift Enhancing Attachment Option: New machine preperation for MAX-ER 2000 attachment includes second swing unit, larger swing pump, piping and control modifications, additional main hoist pump, diverting valve, ratchet and pawl on right split drum, and a larger hydraulic reservoir.
Attachment Options: 15 Ton swivel hook and weight ball, 1,310lbs; 45 Ton hook block, 2,600lbs, single 30" Nom. OD roller bearing sheave grooved for 1-1/8 wire rope, roller bearing swivel hook with hook latch and swivel lock (assembley block), 100 Ton hook block, 3,900lbs, three 30" Nom. OD roller bearing sheaves grooved for 1-1/8" wire rope, roller bearing swivel hook, hook latch and swivel lock; 300 Ton hook block, 9,410lbs, nine 30" Nom. OD roller bearing sheaves grooved for 1-1/8" wire rope, duplex roller bearing swivel hook with hookl latch and swivel lock
Wire Rope: Load line, of 1-1/8" diameter rotation resistant; Whip line, of 1-1/8" diameter rotation resistant
Boom Lengths: Total of 300' (1) 10' No 44 Boom insert and straps; (1) 20' No 44 Boom insert and straps; (4) 40' No 44 Boom inserts and straps
Boom Options: Detachable upper boom point with (1) 30" diameter tapered roller bearing sheave with rope guard for heavy and long reach tops for liftcrane. Boom rigging ladders - set of 2
Tools and Kits: Wind Anemometer
SOLD
