Crane Boom Max. Lifting Capacity: 160 Ton/320,000 lbs
Boom Length: 50 ~ 250 ft
Fixed Jib Max. Lifting Capacity: 59,000 lbs
Max. Jib Length: 100 ft
Max. Combination: 200 ft + 100 ft
Power Plant:
Model HINO P11C-VC
Engine Output: 363 HP / 1,850 rpm
Fuel Tank Capacity: 106 US gal. (400 liters)
Main & Aux. Winch
Max. Line Speed: 390 ft/min (120 m/min):1st layer
Rated Line Pull (Single Line): 29,500 lbs (132 kN)
Wire Rope Diameter: 1-1 / 32 in (26 mm)
Brake Type: Spring set hydraulically released (Negative)
Working Speed:
Swing Speed 2.1 rpm (min-1)
Travel Speed 0.70 / 0.56 mph
Hydraulic System
Main Pumps 3 variable displacement
Max. Pressure 4,626 psi (31.9 MPa)
Hydraulic Tank Capacity 141.3 US gal. (535 liters)
Weight
Operating Weight 304,200 lbs (136 t)
Ground Pressure 11.7 psi (106 kPa)
Counterweight 121,300 lbs
Transport Weight 84,193 lbs
