50 ft of basic boom (butt and top sections) Isuzu 6UZ1 Diesel Engine (Tier Four rated) rated at 362 hp at 2000 rpm Engine “G-Mode†to allow for upwards of 30% fuel savings Kobelco LMI w/12†display and A2B system with overload protection and alarms as well as third wrap sensors Main and Auxiliary Winches with Freefall option included and machine prepped for 3rd drum Main Winch holds 902’ of 26mm wire rope with 29,500 lbf of rated line pull Auxiliary Winch holds 837’ of 26mm wire rope with 29,500 lbf of rated line pull 154,100 pounds of Counterweight and Carbody Weights Self Lifting Device for counterweight installation. 106 US gallon (400 litre) fuel tank 121.5 gallon (460 litre) Hydraulic Reservoir w/cooler and full flow filters with replaceable elements 24 volt electrical system Quick Disconnect Track/Crawler Frames 48†track pads with approximately 11.8 psi ground bearing pressure and 30% gradeability Operators Cab is fully enclosed, full vision w/safety glass, air conditioner/heater, signal horn, windshield wipers, and swing limiter Kobelco KCross Telematics Upper machinery catwalk, ladders and handrails Two (2) front flood lights Main Boom Includes the following for a total of 200’ of boom : One (1) 10’ Boom Insert One (1) 20’ Boom Insert One (1) 40’ “A†Boom Insert (w/ lug) One (2) 40’ Boom Insert (w/o lug) Lifting Accessories Included: One (1) 75 ton capacity, three (3) sheave Hook Block One (1) 19 ton capacity Overhaul Ball Hook Boom Tip Auxiliary Sheave (Rooster Sheave)
