Crane Boom Max. Lifting Capacity 220,000 lbs

Length 40 ~ 200 ft

Fixed Jib Max. Lifting Capacity 24,000 lbs

Max. Length 60 ft

Max. Combination 190 ft 60 ft

Power Plant Model HINO J08E-UV

Engine Output 285 HP / 2,100 rpm

Fuel Tank Capacity 106 US gal. (400 liters)

Main & Aux. Winch Max. Line Speed 390 ft/min (120 m/min) :

1st layer

Rated Line Pull

(Single Line) 25,200 lbs (112 kN)

Wire Rope Diameter 1-1 / 32 in (26 mm)

Brake Type Spring set hydraulically released (Negative)

Working Speed Swing Speed 4.0 rpm (min-1)

Travel Speed 1.07 / 0.71 mph

Hydraulic System Main Pumps 3 variable displacement

Max. Pressure 4,626 psi (31.9 MPa)

Hydraulic Tank Capacity 116.2 US gal. (440 liters)

Weight Operating Weight 198,500 lbs (90.1 t)

Ground Pressure 12.9 psi (101 kPa)

Counterweight 69,000 lbs

Transport Weight 95,128 lbs
