Base Machine Includes: 40 ft of basic boom (butt and top sections) Isuzu 6HK1 Diesel Engine (Tier Four rated) rated at 282 hp at 1900 rpm Engine “G-Mode†to allow for upwards of 30% fuel savings Kobelco LMI w/12†display and A2B system with overload protection and alarms as well as third wrap sensors Main and Auxiliary Winches included and machine prepped for 3rd drum Main Winch holds 771’ of 26mm wire rope with 25,200 lbf of rated line pull Auxiliary Winch holds 525’ of 26mm wire rope with 25,200 lbf of rated line pull 101,000 pounds of Counterweight and Carbody Weights Self Lifting Device for counterweight installation. 106 US gallon (400 litre) fuel tank 100.3 gallon (380 litre) Hydraulic Reservoir w/cooler and full flow filters with replaceable elements 24 volt electrical system Hydraulically Extendable Track/Crawler Frames 36†track pads with approximately 12.9 psi ground bearing pressure and 40% gradeability Operators Cab is fully enclosed, full vision w/safety glass, air conditioner/heater, signal horn, windshield wipers, and swing limiter Kobelco KCross Telematics Upper machinery catwalk, ladders and handrails Two (2) front flood lights Main Boom Includes: One (1) 10’ Boom Insert One (1) 20’ Boom Insert One (1) 40’ “A†Boom Insert (w/ lug) One (1) 40’ Boom Insert (w/o lug) Jib Boom Includes: Not included at this time but “optional†60’ assembly is available Lifting Accessories Includes: One (1) 75 ton capacity, three (3) sheave Hook Block One (1) 13 ton capacity Overhaul Ball Hook Boom Tip Auxiliary Sheave (Rooster Sheave)
