Features
Technical Specifications: Static moment at the turret pin: 229500 (daN/m), 1660295 (lbs/ft) Hyd. boom length: 147' 5" (in) Length: 9560 (mm), 31' 4" (in) Width: 2540 (mm), 8' 4" (in) Height: 2870 (mm), 9' 4" (in) Weight (without oil and fitting): 28250 (kg), 62281 (lbs) Slew torque: 22000 (daN/m), 159157 (lbs/ft) Outriggers extension: 5850 + 5850 (mm), 19' 2" + 19' 2" (in) Outriggers width: 11972 (mm), 39' 3" (in) Pump delivery: 115 (lit/min), 30 (gal/min) Pressure: 320 (bar), 4550 (Psi) Oil tank capacity: 650 (lit), 169 (us gal)
