Features

Technical Specifications: Static moment at the turret pin: 143400 (daN/m), 1037412 (lbs/ft) Hyd. boom length: 32020 (mm), 105' 1" (in) Length: 2441 (mm), 8' 0" (in) Width: 2550 (mm), 8' 4" (in) Height: 2950 (mm), 9' 8" (in) Weight (without oil and fitting): 15365 (kg), 33874 (lbs) Lifting capacity: 11500 (kg), 25353 (lbs) Slew torque: 13000 (daN/m), 94047 (lbs/ft) Slewing speed: 360° - 90 (° – sec), 360° - 90 (° – sec) Outriggers extension: 4140 + 3645 (mm), 13' 6" + 11' 11" (in) Outriggers width: 10105 (mm), 33' 2" (in) Pump delivery: 115 (lit/min), 30 Pressure: 310 (bar), 4408 (Psi) Oil tank capacity: 450 (lit), 118 (us gal)
