Features

Technical Specifications: Static moment at the turret pin: 34500 (daN/m), 254460 (lbs/ft) Hyd. boom length: 16230 (mm), 53’3” (in) Length: 1220 (mm), 4' 0'' (in) Width: 2550 (mm), 8' 4'' (in) Height: 2250 (mm), 7’ 5'' (in) Weight (without oil and fitting): 4070 (kg), 9,205 (lbs) Lifting capacity: 6700 (kg), 14771 (lbs) Slew torque: 3700 (daN/m), 27290 (lbs/ft) Slewing speed: 360° - 33 (° – sec), 360° - 33 (° – sec) Outriggers extension: 1500+1750 (mm), 4' 11''+5' 9'' (in) Outriggers width: 5630 (mm), 18'6'' (in) Pump delivery: 60 (lit/min), 16 Pressure: 280 (bar), 4061 (Psi) Oil tank capacity: 160 (lit), 42 (us gal)
