Standard Equipment
• 40-ton capacity; 5-section, 34–142 ft full-power boom
• 800-lb rotating, non-removable counterweight
• Full-power telescoping boom; quick-reeve sheaves
• Hydraulic boom elevation: -10° to +80°
• Graphical RCL + anti-two-block (A2B) + WADS
• 0–20° tilting cab; heated seat; A/C; skylight; AM/FM/Bluetooth
• 360° continuous “Glide Swing” rotation
• Load-sense hydraulic system; 122-gal reservoir
• Main hoist, 2-speed; 17,250-lb bare-drum maximum pull
• 450 ft of 5/8-in wire rope; 11,280-lb single-line pull
• 20-ton, single-sheave quick-reeve hook block
• Hydraulic outriggers; 0%, 50% and 100% spread positions
• 102-in aluminum decking; ladders; full-width rear bumper; D-rings
• Backup alarm; outrigger-motion alarm; LED lights; owner’s manuals; rotation house lock
• Valspar paint: National Platinum, Gloss Black and Medium Gloss Black
Optional Equipment
• 31–55 ft telescoping jib
• Single front outrigger; hydraulic reservoir mounted on outrigger box
• 72 × 36-in work platform; 1,200-lb main boom / 500-lb jib capacity
• 25-ton, 2-sheave hook block with 4- and 5-part reeving
• Hot-shift PTO; clockwise-rotation pump; remote-mount pump kit
• 5-function proportional radio remote
• Four 24-in aluminum outrigger pads
Chassis
• Freightliner 114SD 8×6
• 0013 12.8L 450V
• Allison 4500 RDS Automatic Transmission with PTO Provision
