Year: 2007
Capacity: 34
Condition: Very-good
Serial #: S0307BT34702143
Location: Colorado
Boom: 70
· 34,000 lb (15,422 kg) maximum lifting capacity
· 80’ (24.38 m) maximum sheave height
· 120’ (36.57 m) maximum sheave height with 24-40’ (7.31 – 12.19 m) jib
· 27-70’ (82.30-21.34 m) three –section full power fully synchronized boom
· Exclusive color coded boom and load charts
· Easy-to-install optional 24’ (7.31 m) one stage pr 24-40’ (7.31 – 12.19 m) two stage telescoping jib, man baskets or work platform increase job capacities
· Electronic Load Moment Indicator and anti-two-block device standard
· Externally located planetary rotation drive for easy accessibility for maintenance
· 2-speed planetary which has 10,5000 lb (4,703 kg) maximum permissible 1 part line, 37,000 lb (16,782 kg) breaking strength, 186 ft/min (57 m/min) maximum line speed
· Dual control station with direct mechanically controlled hydraulic system
· 70 gal (266 L) capacity hydraulic tank
