- 14T capacity crane
- 24-60’ three-section boom
- 22' jib - 92' tip height
- 180 degree stable unit
- Radio remote control
- Hydraulic capacity alert system – maximum capacity sensing device that monitors lift cylinder pressure and displays boom length and angle
- 410o non-continuous rotation with adjustable swing drive
- Hydraulic system – closed center with high pressure pump
- 25 gal (91.6 L) oil tank
- Burst of speed planetary winch with 10,380# of bare drum pull
- 220’ of 9/16” rotation resistant wire rope
- Single line pull 7,700#
- Round headache ball with top swivel – 7 ton (6.35 mt) capacity
- Front out-and-down outriggers with swivel pads
- Outriggers full span 18’ and 13’ mid-span with manual lock pins
- Capacity charts provided for full, mid and fully retracted spans ASH rear stabilizers with 10’ span
- Anti-two block with internal wiring
- 18' Knapheide wood bed
- 36" steel Pro-Tech toolbox
2016 Peterbilt 337 equipped as follows:
- 33,000# GVW
- 256” wheelbase
- 12,000# front axle with 12,000# Taper Leaf Spring suspension
- 21,000# rear axle with Peterbilt Air Leaf Spring suspension
- Front Wheels – 22.5 x 8.25 Alcoa aluminum
- Rear Wheels – 22.5 x 8.25 steel
- Tires – 11R22.5
- PACCAR PX-7 engine – 300 hp@2600 rpm, 660 ft-lbs
- Allison 2500 RDS-P automatic transmission
- Bendix AD-IS air dryer with heater
- Air brakes
- 70 gallon fuel tank
- Peterbilt Ultraride driver’s seat – air ride
- Peterbilt Ultraride passenger’s seat – air ride
- Adjustable steering column – tilt/telescope
- Outside stainless steel sunvisor
- Heated mirrors with 8” spot mirrors
- Power locks and windows
- Concertclass Stereo – AM/FM, WB, USB, BT Phone
- Painted White
