2027 Peterbilt 567 with Manitex 45127SHL Boom Truck Crane
•SC-819
•124' Five Section Telescopic Boom
•2 Piece Jib 30' 6"-55' Jib (QA/G) (124' Boom Only)
•2-speed Hoist w/ Grooved Drum & Hoist Drum Rotation Indicator
•380' (115.82M) 5/8" (16mm) Rotation Resistant Wire Rope
•2 Upper and 3 Lower-Load Sheave Quick Reeve Boom Head
•Audible Outrigger Motion Alarm
•External-Wired Anti-Two Block w/ Lockout
•115 Gallon (435.3 liter) HD Reservoir w/Suction Strainer & Ball Valve
•Boom Hoist Cylinder
•Outrigger Monitoring System for Verification Only
•System Pressure Gauge
•Turret, Rotation Bearing & Swing System
•360° Area of Operation
•LMI
•Continuous Rotation
•Out-And-Down Outriggers with Radio Remote Outrigger Controls
•Front Center Stabilizer
•Tilting Cab w/Heater and Windshield Cover & Upper Hatch Guard
•Engine Monitoring System
•Removable Boom Rest
•Engine Start/Stop
•3-Section Vane Pump-CCW Rotation-Std
•Boom Length and Angle Indicators
•Lower Frame for 10' (3.05m) Flatbed
•Combined Free Swing and Non-Free Swing Functionality
•ROC Solid Radio Remote Outrigger Controls & Control Valve for FBS
•15 Ton 1 Sheave Quick Reeve Block
•7 Ton (6,4 mt) Ball
•Mounted on Peterbilt 567 X15 Endurant Tandem Pusher 290wb
•Cummins X15 500V@1900
•10' Steel Bed
•10-3/4" Steel Rails 445-480"
•PACCAR 160 AMP alternator
•Eaton EXDP-18F118D Automated Endurant XD PRO 18-Speed
•Hotshift PTO
•Endurant XD/PACCAR TX-18 Oil Cooler
•FF: CN 20PLY 425/65R22.5 HTR2 & RR: CN 16ply 11R22.5 HDC3
•26" Aluminum 90 Gallon Fuel Tank LH U/C
•Air seat, high height backrest, adjustable seat track length,1 chamber lumbar support, suspension with fixed damping
Arriving April 2027 Exworks Georgetown TX
Call For Pricing
