50 ton capacity swing cab
155’ five section full powered main boom
Single piece 39’ jib with offsets
2-speed Hoist w/ Grooved Drum
Rotation Resistant Wire Rope ⅝” diameter
Hydraulic Rotation Drum Indicator
5 Ton (4.5 mt) Hook and Ball
Single sheave quick reeve hook block
Deluxe operators cab with 20 degree tilt
Pilot Controls, diesel heater
Heated fully adjustable seat
Engine Monitoring System - Display in upper cab
Full LMI with with all function visual and audible alerts with cutouts
Hard Wired Anti-Two Block w/ Lockout
Engine Start/Stop, Electronic Throttle
Free Swing, Oil Cooler
4 Out-And-down outriggers, 22' over-all spread, with mid span and fully retracted.
Front outrigger 360° Area of Operation, Continuous Rotation
Radio hand held remote outrigger controller.
Aluminum Step Ladder Diamond Plated Aluminum Decking
Mounted on a New 2014 Western Star 4800 Tandem Tandem
Truck VIN 5KKMBBDV6EPFP2204
Detroit Diesel DD13 – 12.8 L 450 HP engine
Eaton Fuller RTLO -18918B - 18 speed transmission
40,000 lbs tandem front axle
46,000 lbs. rear axle – Air Ride Suspension - Full specs available
