STANDARD FEATURES

2-speed Hoist w/ Grooved Drum, Roller Tensioner, Piston Motor

5 Ton (4.5 mt) Hook and Ball

4-Load Sheave Quick Reeve Boom Head

Hard Wired Anti-Two Block w/ Lockout

Boom Hoist Cylinder

System Pressure Gauge

360° Area of Operation

Continuous Rotation

Tilting Cab w/Heater & Windshield Cover

Removable Boom Rest

Engine Start/Stop

Operator's Service/Parts Manuals

Boom Length and Angle Indicators

Electronic Throttle

Free Swing

Hydraulic Rotation Drum Indicator

3-Section, Vane Pump

Diamond Plated Aluminum Decking

4 or 5 Section Telescopic Boom

Signal Horn

400' (122m) or 500' (152m), 5/8" (16mm) Dia. Rotation Resistant Wire Rope

Audible Outrigger Motion Alarm

115 Gal (435 L) or 150 Gal (568 L) Hyd Reservoir w/Suction Strainer & Ball Valve

Turret, Rotation Bearing & Swing System -Mechanical Houselock

New Load Moment Indicator - Full Visual/Audio Capacity Alert w/Shutoff

ROCSolid outriggers; 4 Out-And-down outriggers, 22’ (6.71m) over-all spread.

Features a Hand Held Radio Operated Controller and includes capacities for

Intermediate 13'4" (4.05m) and Retracted 7'2" (2.18m) Spreads.

Outrigger Monitoring System -Verification Only

Front Bumper Stabilizer - for Short lower frame configurations

2 Retractable Ladders for Easy Access to Deck

Aluminum Step Ladder - Deck mounted, multi-position

Oil Cooler

Bubble Level

INCLUDED OPTIONS

Front Bumper Stabilizer with mounting kit

Standard mount installation

A/C for cab

Engine monitoring system

TRUCK

Kenworth T800

Engine: ISX15 500@1800

Transmission: Fuller RTLO16918B 18-speed with pump and oil cooler

Immersion engine block heater 110-120V

Front Axle: Dana Spicer D2200 22K standard track

Front Springs: Taperleaf 20K w/shock absorbers

Rear Axle: Dana Spicer T69-170HP Tridem wide track

Rear Axle Ratio – 4.30

Wheel Diff Lock: T69-170HP all 3 axles

Neway ADZ369 69K Tridem

Front Tires & Wheels: Bridgestone M844F 445/65R22.5, Alcoa 82362 22.5X12.25

Rear Tires & Wheels: Bridgestone L315 445/65R22.5, Alcoa 84360 22.5X14.00, quantity 6

Fuel Tank: 135 US gallon

Heater, A/C w/ integral defrosters and 5 mode rotary controls

Driver Seat: Kenworth air-cushion Plus HB cloth includes dual armrests and suspension cover

Rider Seat: Kenworth Plus Battery Box seat HB cloth with dual armrests

Electric door locks LH/RH
