128’ four section full powered main boom
Two piece 32’ – 49’ jib with offsets
2-speed Hoist w/ Grooved Drum
5 Ton (4.5 mt) Hook and Ball
35 Ton three sheave quick reeve hook block, 4-Load Sheave Quick Reeve Boom Head
Hard Wired Anti-Two Block w/ Lockout
Boom Hoist Cylinder, System Pressure Gauge, 360° Area of Operation, Continuous Rotation
Full Cab w/Pilot Controls and Heater (hydraulic tilt in cab)
Engine Start/Stop, Electronic Throttle, Free Swing, Oil Cooler
Hydraulic Rotation Drum Indicator
400' (122m) or 500' (152m), 5/8" (16mm) Dia. Rotation Resistant Wire Rope
115 Gal (435 L) or 150 Gal (568 L) Hyd Reservoir w/Suction Strainer & Ball Valve
Load Moment Indicator - Full Visual/Audio Capacity Alert w/Shutoff
ROC Solid outriggers; 4 Out-And-down outriggers, 22' (6.71m) over-all spread.
Features a Hand Held Radio Operated Controller and includes capacities for
Intermediate 13'4" (4.05m) and Retracted 7'2" (2.18m) Spreads.
Aluminum Step Ladder - Deck mounted, multi-position, Diamond Plated Aluminum Decking
SOLD
