Standard Features
- 2-speed Hoist w/ Grooved Drum
- 5 Ton (4.5 mt) Hook and Ball
- 4-Load Sheave Quick Reeve Boom Head
- Hardwired Anti-Two Block w/ Lockout
- Boom Hoist Cylinder
- System Pressure Gauge
- 360° Area of Operation
- Continuous Rotation
- Tilt Cab w/ and Heater
- Removable Boom Rest
- Engine Start/Stop
- Operator's Service/Parts Manuals
- Boom Length and Angle Indicators
- Air Throttle
- Foot Throttle
- Signal Horn
- 4 Section Telescopic Boom
- 400 (115.82m) 5/8" (16mm) Rotation Resistant Wire Rope
- Audible Outrigger Motion Alarm
- 115 Gallon (435 liter) Reservoir w/Suction Strainer & Ball Valve
- Turret, Rotation Bearing & Swing System
- Load Moment Indicator-Audio/Visual capacity Alert w/Shutoff
- 4 Out-And-down Outriggers, 22'(6.71m) spread including Capacities for Intermediate 13'4" (4.05m) and Retracted 7'2" (2.18m) Spreads
- 3-Section Vane Pump
- Lower Frame for 10' (3.05m) flatbed
- Oil Cooler
- Pilot Controls
- Bubble Level
- Outrigger Monitoring System for Verification Only
|
Included Options
- 35-Ton 2 sheave load block
- New tilting cab
- Telemetry engine monitoring system
- Upper and boom all white and subframe outriggers black
Truck
- 2013 Kenworth C500
- Engine: ISX15 550 550@2000 1850@1200
- Transmission: Fuller RTLO18918B 18-speed
- Immersion engine block heater 110-120V/1500W
- Front Axle: Dana Spicer D2200 40k dual twin steer
- Rear Axle & Equipment: Dana Spicer T69-170HP WT VARCAP Tridem wide track
- Neway ADZ378
- Rear Axle Ratio-4.78
- Front Tires & Wheels: Bridgestone M844F 445/65R22.5 20PR, Alcoa 83365 22.5X13.0
- Rear Tires & Wheels: Bridgestone M775 11R24.5 16PR, Alcoa 98367 24.5X8.25, quantity 12
- Fuel Tanks: 1 100 US gallon, located RH & LH behind cab
- DEF tank located LH
- Driver & Rider Seat: Kenworth air-cushion premium plus HB Mordura includes dual armrests and suspension cover
- Electric door locks
- Electric powered window lifts
