40 TON MANITEX 40124SHL 2015 KENWORTH T800
CRANE
MANITEX 40124SHL,
40 TON CAPACITY W/ REAR MOUNTED RIDER SEAT,
124 FT 5-SECTION TELESCOPIC BOOM,
5-SHEAVE QUICK REEVE BOOM HEAD,
189' TIP HEIGHT WITH 55 FT JIB,
TILTING ENCLOSED CAB W/ HEAT,
FREE SWING OPTION WITH FOOT BRAKE,
380' 5/8" ROTATION RESISTANT WIRE ROPE,
PILOT OPERATED DUAL AXIS CONTROLLERS,
LMI CAPACITY ALERT WITH VISUAL DISPLAY & OVERLOAD SHUT-OFFS,
HARDWIRED ANTI-TWO BLOCK SYSTEM,
360 DEGREE AREA OF OPERATION W/ CONTINUOUS ROTATION,
4 HYDRAULIC OUT-AND-DOWN OUTRIGGERS,
LOAD CHARTS FOR FULLY EXTENDED/INTERMEDIATE/RETRACTED OUTRIGGERS,
10 FT BED & RETRACTABLE LADDERS,
PAINTED STD MANITEX COLORS,
ALL STANDARD EQUIPMENT,
STANDARD MANITEX FACTORY WARRANTY.
Additional Options:
55' Two Part Jib,
Front Stabilizer,
Tilting heated cab,
Rotation Resistant 5/8" cable,
Engine Management System in cab,
Windshield Cover
TRUCK
NEW 2015 KENWORTH T800,
CUMMINS ISX15 - 450 HP TURBO DIESEL ENGINE W/ INTERBRAKE,
20,000# FRONT AXLE,
69,000# TRI-DRIVE REAR AXLES,
DANA T69-TRIDEM REAR AXLES,
FULLER RTLO 16913A - 13 SPEED,
4330 REAR AXLE RATIO,
H.D. FRONT AND REAR SPRINGS,
FULLER RTO16913A 13 SPD MANUAL TRANSMISSION,
WITH PUMP AND OIL COOLER,
1650 LB-FT TORQUE,
445-65R22.5 FRONT TIRES,
11R-22.5 16 PLY REAR TIRES,
ALCOA ALUMINUM FRONT AND REAR OUTER WHEELS,
FULL DOUBLE FRAME,
AIR BRAKES W/ ANTI-LOCK BRAKING SYSTEM,
POWER STEERING,
3 PACCAR GP31 BATTERIES 2100 C.C.A,
FRONT TOW HOOKS,
CUMMINS ISX15 IMMERSION ENGINE BLOCK HEATER 110-120V,
BATTERY JUMPER TERMINAL,
PACCAR 12 VOLT STARTER,
VERTICAL EXHAUST-STAINLESS STEEL GUARD AND FAIRING,
AIR CONDITIONING,
AIR HORN,
PACCAR 130 AMP ALTERNATOR,
75 GAL ALUMINUM FUEL TANK (LH),
60 GAL ALUMINUM FUEL TANK (RH),
1-11 GALLON D.E.F. TANK,
KENWORTH AM/FM/CD RADIO,
AIR RIDE DRIVER'S SEAT,
HEATED STAINLESS STEEL MIRRORS,
ONE PIECE CURVED WINDSHIELD,
POWER WINDOWS DRIVER SIDE,
COMPLETE GAUGE PACKAGE,
PAINTED KENWORTH WHITE,
STD KENWORTH FACTORY WARRANTY.
