STANDARD FEATURES

2-speed Hoist w/ Grooved Drum & Hoist Drum Rotation Indicator

5 Ton (4.5 mt) Hook and Ball

4-Load Sheave Quick Reeve Boom Head

Wired Anti-Two Block w/ Lockout

Boom Hoist Cylinder

System Pressure Gauge

360° Area of Operation

Continuous Rotation

Ride-around Operator Station with Seat

Removable Boom Rest

Engine Start/Stop

Operator's Service/Parts Manuals

Boom Length and Angle Indicators

Air Throttle

Foot Throttle

No Free Swing (Free swing is avail. option)

5 Section Telescopic Boom

380 (115.82M) 5/8" (16mm) rotation Resistant Wire rope

Audible Outrigger Motion Alarm

100 Gallon (379 liter) Reservoir w/Suction Strainer & Ball Valve

Outrigger Monitoring System for Verification Only

Turret, Rotation Bearing & Swing System

Load Moment Indicator-Audio/Visual Capacity Alert w/Shutoff

4 Out-And-down Outriggers, 22'(6.71m) spread including Capacities for Intermediate 13'4" (4.05m) and Retracted 7'2" (2.18m) Spreads

2 Retractable Ladders for Easy Access to Bed

3-Section Vane Pump

Lower Frame for 10' (3.05m) flatbed

Oil Cooler

Pilot Controls

Bubble Level

ROC solid radio remote outrigger controls & control valve for FBS

INCLUDED ITEMS

40124S 40 Ton with 124’, 5 Section Telescoping Boom – NO FREE SWING

Basic Cab & Heat

10' Steel Bed

Rear Mount Installation

20 Ton, 1-Sheave Block

Hydraulic Reservoir, Chassis Mounted required when there is no be

48” X 18” X 18” Tool Box

TRUCK

2011 Freightliner SD 114

Detroit DD13 12.8L, 450 HP

Jacobs Compression Brake

Allison Automatic Transmission

Phillips block heater 110V 1500W

Cruise Control

Dual power steering gears: 20K TRW TAS65

Detroit DA-F-20-5 20K Front Axle

Meritor 69,000 LB. Tridem Rear Axle

Hendrickson Primaxx Air Ride Rear Suspension

Front Tires: Michelin XZL 445/65R 22.5 20 PR on Aluminum Wheels

Rear Tires: Michelin XZL 445/65R 22.5 (Qty68) on Aluminum Wheels

120 US Gallon Rectangular Aluminum Fuel Tank

9.0 US Gallon DEF Tank

Heat/Defrost/Air Conditioning

Air Suspension High Back Drivers Seat

Air Suspension High Back Passenger Seat

Air Ride Cab

AM/FM/CD/Weather Band Radio

30,690 Miles
