STANDARD FEATURES
Serial Number 128083
Basic Machine w/ 100’ 4-section Boom
2-speed Hoist w/ Grooved Drum
3 - Sheave Quick Reeve Boom Head
Radio Anti-Two Block w/ Lockout
Boom Hoist Cylinder
System Pressure Gauge
360° Area of Operation
Continuous Rotation
Ride-around Operator Station with Cab
Removable Boom Rest
Engine Start/Stop
Operator's Service/Parts Manuals
Boom Length and Angle Indicators
Air Foot Throttle
Free Swing
Signal Horn
Pilot Controls
4 Section Telescopic Boom
380 (115.82M) 5/8" (16mm) rotation Resistant Wire rope
Audible Outrigger Motion Alarm
100 Gallon (379 liter) Reservoir w/Suction Strainer & Ball Valve
Turret, Rotation Bearing & Swing System
Load Moment Indicator-Audio/Visual Capacity Alert w/Shutoff
4 Out-And-down Outriggers, 22'(6.71m) spread including Capacities for Intermediate 13'4" (4.05m) and Retracted 7'2" (2.18m) Spreads
2 Retractable Ladders for Easy Access to Bed
3-Section Hydraulic Pump
10' (3.05m) steel flatbed
Oil Cooler
Bubble Level
INCLUDED ITEMS
2 Piece 55’ Jib
35-ton 3-Sheave Hook Block
Crane operator’s enclosed cab
McKessick 7 ton ball
TRUCK
2007 Sterling 9500
VIN #: 2FZHAZCV27AV66349
Mercedes 450 HP Engine with Engine Brake
10 Speed Transmission
20,000 Dana Spicer EFA20F4 Front Axle
40,000 Dana Spicer DSP41Tandem Rear Axles
Leaf spring Front Suspension
Hendrickson RTE-403 Rear Suspension
Locking Differential
Front: 425/65R22.5 Tires on Steel Wheels
Rear: 11R22.5 tires on Steel Wheels
60 Gallon Aluminum Fuel Tank
48” Tool Box
A/C & Heat
AM/FM Radio
