STANDARD FEATURES

• 2-speed Hoist w/ Grooved Drum
• 3-Load Sheave Quick Reeve Boom Head
• 380' (115.82m) 5/8" (16mm) Rotation Resistant Wire Rope
• Dual Operator Control Stations
• Radio Anti-Two Block w/ Lockout
• Boom Hoist Cylinder
• 3-Section Hydraulic Pump
• System Pressure Gauge
• 372° Non Continuous Rotation
• Removable Boom Rest
• Engine Start/Stop
• Operator's Service/Parts Manuals
• Boom Length and Angle Indicators
• Mechanical Throttle
• Foot Throttle
• Signal Horn
• Bubble Level
• 5 Section Telescopic Boom
• Subframe for 22' (6.71 m) Bed
• 115 Gallon (379 liter) Reservoir w/Suction Strainer & Ball Valve
• Pedestal, Turret, Rotation Bearing & Swing System
• Load Moment Indicator w/Internal length Cable-Audio/visual Capacity Alert w/ Shut off
• Hermetically sealed Printed Circuit Board Electrical System
• Audible Outrigger/Stabilizer Motion Alarm
• Out and Down Rear Stabilizers w/ (18 '6" Spread)
• Beverage Cup Holders
• Serial # 136987

INCLUDED ITEMS

• Basic Machine w/124’ Five-Section Telescopic Boom
• 22' flatbed body with steel diamondette floor
• Standard Mount Installation
• 30 Ton, 3 Sheave Hook Block
• 1 Piece – 31’ jib
• Front Center Stabilizer (Requires Additional Mounting Charge)
• Mounting--Front Center Stabilizer
• Control valve for operation of single stabilizer, Required w/FBS

TRUCK

• Sterling LT9500 Single Steer Tandem Rear Chassis
• Mercedes Benz MBE 4000, Diesel Engine, 410 HP
• Cruise Control
• Eaton Fuller 8LL Transmission, 10 Speed
• Meritor MFS-20-133A, 20K Front Axle
• Meritor RT-40-145, 40K Tandem Rear Axle
• Hendrickson RT 403, 40,000 Spring, Rear Suspension
• 4.11 Rear Axle Ratio
• Wheel Diff Locks
• Front Tires: 425/650R 22.5 Tires on Steel Disc Wheels
• Rear Tires: 11.R 22.5 Tires (Qty 8) on Steel Disc Wheels
• Single 60 US Gallon Aluminum Fuel Tanks
• Heat/Defrost/Air Conditioning
• Air Suspension Drivers Seat
• Fixed passenger seat
• AM/FM/ Radio
• Serial # 2FZHAZCV27AV66397
