STANDARD FEATURES
2-speed Hoist w/ Grooved Drum
5 Ton (4.5 mt) Hook and Ball
3-Load Sheave Quick Reeve Boom Head
Hard Wired Anti-Two Block w/ Lockout
Boom Hoist Cylinder
System Pressure Gauge
72° Non Continuous Rotation
Removable Boom Rest
Engine Start/Stop
Operator's Service/Parts Manuals
Boom Length and Angle Indicators
Electronic Throttle
Foot Throttle
Signal Horn
Bubble Level
Outrigger Monitoring System for Verification only.
3-Section Hydraulic Pump
Auxiliary Winch with Auxiliary Sheave Head
4 Section Telescopic Boom
335' (102.11m) 9/16" (14.3mm) Rotation Resistant Wire Rope
Subframe for 18' (5.5m) Bed
115 Gallon (435 liter) Reservoir w/Suction Strainer & Ball Valve
Pedestal, Turret, Rotation Bearing & Swing System
Dual Operator Control Stations
Load Moment Indicator w/Internal Length Cable
Audio/visual Capacity Alert w/ Shut off
Hermetically sealed Printed Circuit Board Electrical System w/LED Circuit Status Indicators
Audible Outrigger/Stabilizer Motion Alarm
A-frame Link Type Rear Outriggers (22' 4" Spread Width)
Out and Down Front Stabilizers (19 '7" Spread)
Rear Stabilizer
INCLUDED OPTIONS
Standard mount installation
18’ heavy hauler steel bed
HYCAS hard wired ATB 102’
3-Section vane pump – clockwise in lieu of standard (for automatic transmission)
Hot Shift PTO
Drive shaft for pump installation
