CRANE CONFIGURATION

SCOPE OF DELIVERY:

- basic machine

CRANE CARRIER and CRANE SUPERSTRUCTURE

Engine exhaust emission level IV according to 97/68/EG and level Tier 4-final according to EPA/CARB

Working equipment:

- Double lattice-type swing-away jib, 10.8 m – 19 m, mounted to the boom at 0°, 20 ° and 40°

- Hydraulic adjustment of the swing-away jib for infinitely variable adjustment between 0° - 40°

- Preparation for second hoist

- Hook block 59.1 to with 3 sheaves with double hook

- Load hook 8.8 t

- Second bolster

Additional equipment - Carrier:

- Additional engine independent heater incl. timer – carrier cabin

- Drive 10 x 8

- Eddy-current brake type TELMA

- storage box, combined for slings and support timber

- VarioBase - variable supportbase

- Emergency-stop switch for carrier and crane cabin

- Drivers seat air-condition (incl. seat heating)

Additional equipment - Superstructure

- Additional counterweight 11 t (for total counterweight 26 t)

- Additional counterweight 9 t (for total counterweight 35 t)

- Additional engine-independent heating in superstructure cabin incl. timer

- Workspace boundary

- Second hoist limit switch

- Two working floodlights at pivot section electrically adjustable

- Flight warning light, switchable between continuous light and flash light

- Crane operator seat air-conditioned (incl. seat heating)

- Emergency operation of crane hydraulic

- LICCON data logger with evaluation software – Liftanalyser

- LICCON - work planner

(In the meantime the crane get labled).
