Year: 1992
Capacity: 70.00
Condition: Excellent
Hours: 12000
Unit #: BIGKMK4070
Location: Germany
Boom: 39
| Krupp KMK 4070 Specifications - 70 t Telescopic crane | |||
| Building type: | Telescopic crane | ||
| Max. capacity: | 70 t at 3 m | Max. loadmoment: | - tm |
| Axles: | 4 | Total weight: | 48 t |
| Boom: | |||
| Telescopic boom: | 11,6-38,1 m | Boom sections: | 4 |
| Boom luffing up to: | 84° in 45 seconds | Boom extension: | 11,6-38,1 m in 150 seconds |
| Superlift: | - | Intermediate sections: | - m |
| Folding jib: | 10/16 m ofsettable at angle 0/16/30° | ||
| Fixed jib: | - m ofsettable at angle -° | Fly jib: | - m |
| Main boom foot pin horizontal offset X: | -2080 mm | Main boom foot pin vertical offset Y: | - mm |
| Max. slewing speed: | 2,4 rpm | ||
| Max. line speed: | 120 m/min | Max. line pull: | 61 kN |
| Dimensions: | |||
| Total length: | 13270 mm | Tail swing: | 3500 mm |
| Carrier length: | 10580 mm | Width: | 2500 mm |
| Outer turning radius : | 10650 mm | Inner turning radius: | 5550 mm |
| Turning radius boom head: | 11850 mm | Turning radius folding jib: | 12300 mm |
| Outrigger base: | 8350 x 7200 mm | Reduced outrigger base: | 8350 x 4770 mm |
| Track (Crawler cranes): | - mm | Track width (Crawler cranes): | - mm |
| Drives: | |||
| Carrier engine: | MB OM 432 A | Power/Weight-Ratio: | 5.21 kW/t |
| Power: | 250 kW / 340 PS | Max. torque: | 1500 Nm 1200 rpm |
| Transmission: | ZF Getriebeautomat 5 HP 600 | Gears: | 5 1 (Forward reverse) |
| Max. speed: | 68 km/h | Gradeability: | 78 % |
| Drive / Steering (standard): | 8x6x8 | Drive / Steering (option): | 8x8x8 |
| Tyres (standard): | 14.00 R25 | Tyres (option): | 16.00 R25 |
| Superstructure engine: | - | ||
| Power: | - kW / - PS | Max. torque: | - Nm at - rpm |
| Counterweight: | |||
| Superlift mast: | - m | Radius A-Bock: | - mm |
| Max. counterweight: | 13,4 t | Superlift counterweight: | - t |
BIG EQUIPMENT GROUP USA (WE CAN FINANCE AND ACCEPT LC PAYMENT)
