2024 Grove GMK6450-1, S/N: 6400-4045, 500 Ton Capacity Hydraulic All Terrain Crane with 12 x 8 x 12 Carrier, Equipped As Shown Below:
- 51 Ft to 197 Ft 5-Section Hydraulic Pinned Main Boom
- Seven Sheave Boom Nose
- Auxiliary Boom Nose
- Mega-Wing-Lift System
- 82 Ft to 259 Ft Luffing Jib and 39 Ft to 210 Ft Fixed / Offsettable Jib (3° to 25°)
- Includes Spreader to Use Luffing Jib with MWL
- 3.3 Ft Adapter Which Can Be Used to Make Up 13.1 Ft or 24.6 Ft Heavy Duty Jib
- Rigging Winch for Luffing Jib or Fixed / Offsettable Jib
- CCS Rated Capacity Indicator w/ Graphic Display
- Full Vision Hydraulically Tiltable Operator's Cab
- Comfort Seat w/ Adjustable Suspension
- Comfort Package: Table, Tablet and Smart Phone Stowage
- Armrest Mounted Dual Axis Crane Control Joysticks
- Stereo Radio w/ Bluetooth in Both Cabs
- Air Conditioning in Both Carrier & Superstructure Cabs
- Mercedes OM 473LA Tier 4F Diesel Engine
- Main and Auxiliary Hoists w/ Drum Rotation Indicators
- 1,247 Ft 24 mm Wire Rope for Main Hoist
- 2,264 Ft 24 mm Wire Rope for Auxiliary Hoist
- Oil Coolers for Carrier & Superstructure
- 297,500 Lbs Total Counterweight
- MAXbase Variable Positioning Outriggers
- Outrigger Length Control
- Hydraulic Disconnect for All Outrigger Beams
- Removable Rear Outrigger Box
- Steel Outrigger Pads
- ZF TraXon 12, Electronic Automatic Shifting
- Hydraulic Retarder Integrated in Gear Box (Intarder)
- Megatrak Hydropneumatic Suspension
- 525/80 R25 On / Off Highway Radial Tires on Steel Rims
- Reversing Camera System
- Two (2) Additional Spotlights on Rear of Carrier for Reversing
- Two Worklights Mounted on Top of Boom Base Section
- Boom Mounted Aircraft Warning Light (Flashing)
- Cover Package for Carrier Bottom Protection, Hose Reel Cover and Cable Reel Cover
- Trailing Boom Float Kit w/ Trailing Boom Boost
- Emergency Operation without Transformer
- External Starting Outlet
- 176 Ton, 5 Sheave Hookblock, Double Hook
- 44 Ton, 1 Sheave Hookblock, Single Hook
- 18 Ton Overhaul Ball, Single Hook
