1987 Gottwald AMK100, 90 Metric Ton, All Terrain Crane; CranesList ID: 1062,
- 41’- 152’ Four Section Full Power Boom with Auxiliary Lifting Sheave
- 69' Fixed Jib off-settable @ 10 Degrees
- Main and Auxiliary Winches
- Overload warning (visual and audible) and automatic motion cut‑off when limits are exceeded (hoist up, luff down, telescope out, possibly slewing). Boom angle and length indication visible to the operator. Actual load indication at hook (via pressure transducers in hoist/boom cylinder circuit, or via LMI). Anti‑two‑block device (A2B) with switch at boom tip that stops hoist up / telescope out when tripped - SUBJECT TO FINAL CONFIRMATION
- Hook Block
- Mercedes-Benz UP - SUBJECT TO FINAL CONFIRMATION
- 12 Ton Fixed Counterweights - SUBJECT TO FINAL CONFIRMATION
- Faun five axle carrier
- Man Diesel Engine - SUBJECT TO FINAL CONFIRMATION
- Allison Wandler-Lastschaltgetriebe Transmission - SUBJECT TO FINAL CONFIRMATION
- Front and Rear Tires: 14.00-24 PR22 - SUBJECT TO FINAL CONFIRMATION
- Outrigger base: 6750 x 8000 mm.
http://www.CranesList.com
LOCATED IN INDIA!
