Crane Capacity - 6.0t x 2.6m

Max. Working Radius - 16.1m

Max. Lifting Height- 16.7m (22.0m with fly jib)

Max. Reach Below Ground - 24.5m (4 falls)

Pick & Carry Capacity - 2,000kg

Travel Speed - 0-3.1km/h

Travel Ground Pressure (with rubber pads) - 51.2kPa (0.52kgf/cm2) [54.5kPa (0.56kgf/cm2) w/blade & fly jib]

Engine - ISUZU 4LE2XBJB / Diesel

Engine Rated Output - 44.6kW/2000min-1 (60.6PS / 2000rpm)

Dimensions (with rubber pads) - 6,610mm (L) x 2,490mm (W) x 2,910mm (H)

Tail swing - 1,550mm

Machine Weight (with rubber pads) - 15,030kg (15,710kg w/blade, 15,330kg w/fly jib, 16,010kg w/ blade & fly jib)
