Features
INTELLIGENT LIGHTWEIGHT DESIGN OFFERS AN OPTIMIZED MOUNTING CONCEPT
Shorter load cycle times due to High Speed extension
High operator friendliness thanks to radio remote control
Maximum utilisation of the working range due to HPSC
More lifting power due to E-HPLS
Specs
- Max. lifting moment: 65050.0 ft_lbs
- Max. lifting capacity: 12570 lb
- Max. hydraulic outreach: 38' 9''
- Max. manual outreach: 52' 6"
- Slewing angle: 400
- Slewing torque with 1 gear: 7230.0 ft_lbs
- Stabilizer spread (std): 16'
- Fitting space required (std): 2' 4''
- Width folded: 7' 7''
- Max. operating pressure: 5220 psi
- Pump capacity: 10.6 - 13.2 US gpm
- Dead weight (std): 2380 lbs
