Features

STANDARD UNITS EQUIPPED WITH THE FOLLOWING:
Boom: Full power telescoping cylinder with integral holding valve in the telescoping cylinder. Three (3) quick reeve cast iron sheaves in the boom nose. Boom Elevation: One(1) double acting hydraulic lift cylinder with integral holding valve. (-10° to 80°)
Rated Capacity Limiter & Anti-two Block Systems: Graphical RCL
system with audio/visual warning system and control lever lockout. Electronic display of boom angle, boom length, relative
load moment indication, rated load, load, radius and boom tip height. Standard WADS (Work Area Definition System) allows operator to pre-select and define safe working areas. When crane
approaches set limits, audio/visual warnings alert the operator of the jobsite obstructions.
Crane Cab: All steel construction with acoustical lining and tinted glass, deluxe seat with armrest mounted single axis hydraulic pilot controllers, windshield with electric wiper, sliding skylight with
sunshade and electric wiper, Air conditioning, hot water cab heater with defroster (diesel fired with remote diesel tank mounted to cab), circulating fan, fire extinguisher, dual cab mounted work lights, engine start/stop switches and signal horn.
Swing: 360° continuous rotation, planetary "Glide Swing" with foot actuated multi-disc brake and pinion guard.
Hydraulic System: Pressure compensated, load sense, closed-
center hydraulic system with one (1) left-hand rotation, variable displacement pump. 100 gal (378,5 L) hydraulic reservoir, external sight level indicator, filter condition indicator, oil temperature gauge and boom rest mounted oil cooler with electric fan and butterfly valve on the suction line. Auxiliary winch valve section only is included.
Hoist: One (1) main hoist with grooved drum, two-speed power up and down, automatic multi-disc brake, electronic drum rotation indicator (DRI), last layer indicator (LLI), and drum cable follower. Bare drum maximum pull 15,000 pounds (6.308,8 kg) low speed.
Wire Rope: 450 ft (137,2 m) of 5/8 in (16 mm) diameter 35x7 (5:1 design factor) for main hoist. Single line pull 11,250 pounds (5.102,9 kg)Hook Block: 20 ton (18,1 mt) 410 pounds (186 kg) single sheave, "Quick Reeve" type block with swivel hook and safety latch.
Outriggers: Hydraulic front and rear. Two (2) section extendable beams wit integral check valves for 360° operation, 20 in (508
mm) diameter polymeric outrigger pads and three (3) position settings (0%, 50% & 100%). Controls located in crane cab and on both ides of subframe. Outrigger Monitoring System included.
Stabilizers: Single front outrigger (SFO) -folds for tilting truck hood (requires extended front chassis frame rails). SFO has "first up" feature.
Decking/Ladders/Bumpers: Full-length aluminum flat decking on both sides of crane, fold down ladder on drivers side of decking for crane cab access, one(1) removable ladder stowed/locked at
the rear of crane frame that can be used for passenger side & driver side rear for crane access, two(2) mud flaps which attach to truck frame and full width rear bumper which bolts to truck frame
Miscellaneous Standard Equipment: 360°stable, Back-up alarm, hour meter in crane cab, outrigger motion alarm, marker and indicator lights, two(2) English language owner's manuals (1 paper & 1 USB flash drive), EET included and rotation house lock (for when boom is stowed over the truck).
Standard Paint: Valspar Duraspar® 2K Epoxy Primer and Valspar Duraspar® Ultra 2K Urethane paint -"National Platinum" color for turret, crane cab and base boom section; standard "Black" for
hydraulic reservoir, SFO, torsion box (frame), inner outrigger be
ams, and inner boom sections.

Included options

• 45 Ton (40,8 mT) Capacity, standard unit equipped with a five(5) section, 31 -127 ft
• 31 -55 ft (9,4 -16,7 m) telescoping boom extension includes 24 ft (7,3 m) manual pull out section to 55 ft (16,7 m)
• Round Headache ball with swivel
• Boom mounted auxiliary winch. 15,000 lbs (6.803,8 kg) bare drum pull on low speed. 450 ft (137,1 m) of 5/8 in (16 mm) rotation resistant rope
• Standard Mounting
• Extended Torsion Box
• PTO
• Counter-clockwise rotation pump (Manual Transmission, Eaton
Ultrashift

  • Year: 2022
  • Capacity: 45.00
  • Condition: New
  • Unit #: BM-3669
  • Serial #: 302693
  • Location: Houston Texas USA
